101 x 400 mm Hardware- Max. packed bed volume: 1800 ml- Max. packed bed length: 225 mm- Max. operating pressure:

• ·Packing: 138 bar / 2000 psig
• ·LC Operation: 138 bar / 2000 psig

- Max. operating temperature:

• ·Packing: 15°C - 30°C

• ·LC Operation: 4°C - 60˚C





101 x 700 mm Hardware- Max. packed bed volume: 3600 ml- Max. packed bed length: 450 mm- Max. operating pressure:

• ·Packing: 138 bar / 2000 psig
• ·LC Operation: 138 bar / 2000 psig

- Max. operating temperature:

• ·Packing: 15°C - 30°C
• ·SFC Operation: 4°C - 60˚C

PED 97/23/EC
Pressure Equipment Classification:
- Vessel as per Article 3, Section 1.1 (a), first and second indent
Operating Fluids: Fluid Group 1 + 2
F.D.A. Approved Materials
